4 Series B MSO Mixed Signal Oscilloscope

The versatile 4 Series B MSO has the performance to address tough design challenges and a user interface that works the way you expect. With a new upgraded processor system, it delivers accurate measurements faster with an outstanding range of analysis tools.

Base Price
HKD 78,200 +
Bandwidth

Up to1.5GHz

Record length

Up to62.5M

ANALOG CHANNELS

4or6

Vertical Resolution

12bits

What’s new in the 4 Series B

  1. Faster processor
    • > 2X more responsive UI
    • > 1.5X faster data transfers
    • Faster analysis and serial decoding
  2. New display with greater contrast and viewing angle
  3. Two USB 3.1 host ports
  4. Fast e*Scope browser-based remote access
MSO46B Oscilloscope
4 Series B MSO Power Analysis

Big HD display and award-winning user interface

With the same made-for-touch user interface technology as the award-winning 5 Series in a compact package, the 4 Series B MSO sets a new expectation of how a scope should work.

  • 13.3-inch high-contrast HD display
  • 6.1-inch (15.5 cm) deep bench-friendly footprint

Watch a short video

Precise measurements and up to 6 super-flexible channels

  • Fine signal detail and accurate measurements on all channels
    • 12-bit vertical resolution (16-bit in high res mode)
    • 6.25 GS/s on all analog and digital channels
    • Up to 62.5 Mpoints record length
  • Any channel can show a waveform, RF spectrum, or both
  • Any input can be used to view eight digital channels by connecting a logic probe

Watch a short video

4 Series B MSO EMI Setup
Measurement Analysis Software

Outstanding analysis

Discover the capability the 4 Series B can bring to your bench

  • Broad range of smart TekVPI probes
  • Multi-channel spectrum analysis
  • Up to 48 digital logic inputs
  • Over 25 available serial protocols
  • Built-in arbitrary/function generator
  • AC/DC power supply measurements
  • Automated double pulse testing
  • 3-Phase power analysis
  • Field upgradeable -- get the tools you need now or add them later, without having to return the instrument

Watch a short video

Find out more about upgrades with this guide

November 2023 firmware release enables these new features and options

Upgrades on all instruments

  • New measurement annotations display reference levels, top/base levels, start/end points and more
  • New trace file records commands sent to the programming interface
  • New e*Scope authentication

Upgrades on instruments with advanced analysis options



Updated PC Software

  • TekScope waveform analysis software now incorporates many of the new features and options listed above

Already have a 4 Series? Get your update.

Download new firmware

Specs at a glance

Input Channels

  • 4 or 6 FlexChannel inputs
  • Each FlexChannel provides 1 analog signal input or 8 digital logic inputs with TLP058 probe

Bandwidth1

  • 200 MHz, 350 MHz, 500 MHz, 1 GHz or 1.5 GHz

Sample Rate

  • 6.25 GS/s on all analog/digital channels

Record Length

  • 31.25 or 62.5 Mpoints

Vertical Resolution

  • 12 bits
  • Up to 16 bits in High Res mode
Included probes and accessories

1 - Optional and upgradeable
2 - Free with product registration
3 - Partial list of decode and analysis options. See datasheet for all supported buses.

Signal Generation1

  • Arbitrary, Sine, Square, Pulse, Ramp, Triangle, DC Level, Gaussian, Lorentz, Exponential Rise/Fall, Sin(x)/x, Random Noise, Haversine, Cardiac

Digital Voltmeter2

  • 4-digit AC RMS, DC
  • DC+AC RMS voltage

Trigger Frequency Counter2

  • 8-digit

Advanced Analysis

  • Spectrum View Mixed Domain Analysis
  • Automated Power Measurements1
  • 3-Phase Power Measurements1

Protocol Support3

  • 10BASE-T, 100BASE-TX
  • CAN, CAN FD, LIN, FlexRay
  • I2C, SPI
  • MIL-STD-1553, ARINC 429
  • RS-232, RS-422, RS-485, UART
  • SPMI
  • SVID
  • USB 2.0 LS, FS, HS

Display

  • 13.3-inch (338 mm)
  • HD color (1920 x 1080) capacitive touchscreen

Dimensions (H x W x D)

  • 287 mm x 405 mm x 155 mm
  • (11.3 in x 15.9 in x 6.1 in)

Weight

  • 16 lbs (7.3 kg)
Included probes and accessories
1 - Optional and upgradeable
2 - Free with product registration
3 - Partial list of decode and analysis options. See datasheet for all supported buses.

Looking for even more performance?

The 4 Series B MSO is part of a family of class-leading oscilloscopes at different performance levels and price points.

Explore The Range

Model Analog Bandwidth Analog Channels Digital Channels Sample Rate Record Length List Price Configure And Quote
MSO44

200 MHz to 1.5 GHz

4

Up to 32 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 78,200 Configure & Quote
MSO44B

200 MHz to 1.5 GHz

4

Up to 32 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 79,700 Configure & Quote
MSO46

200 MHz to 1.5 GHz

6

Up to 48 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 105,000 Configure & Quote
MSO46B

200 MHz to 1.5 GHz

6

Up to 48 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 107,000 Configure & Quote
Model Analog Bandwidth Analog Channels Digital Channels Sample Rate Record Length List Price Configure And Quote
MSO44

200 MHz to 1.5 GHz

4

Up to 32 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 78,200 Configure & Quote
MSO44B

200 MHz to 1.5 GHz

4

Up to 32 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 79,700 Configure & Quote
MSO46

200 MHz to 1.5 GHz

6

Up to 48 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 105,000 Configure & Quote
MSO46B

200 MHz to 1.5 GHz

6

Up to 48 (optional)

6.25 GS/s

31.25 M to 62.5 M

HKD 107,000 Configure & Quote
  Tektronix
4 Series B MSO
Tektronix
MDO4000C
Keysight
4000T X-Series
LeCroy
HDO4000A Series
Rohde & Schwarz
MXO4 Series
Bandwidth 200 MHz to 1.5 GHz 200 MHz to 1 GHz 200 MHz to 1.5 GHz 200 MHz to 1 GHz 200 MHz to 1.5 GHz
Analog Channels 4 or 6 4 2 or 4 4 4
Digital Channels (optional) Up to 48 16 16 16 16
Sample Rate (All Channels) 6.25 GS/s Up to 5 GS/s 2.5 GS/s 2.5 GS/s 2.5 GS/s
Vertical Resolution 12 bits 8 bits 8 bits 12 bits 12 bits
Record Length (All Channels) 31.25 M
62.5 M (optional)
20 M 4 M 12.5 M
25 M (optional)

400 M
800 M (optional)

Integrated Arbitrary/Function Generator (optional) 1 x 50 MHz 1 x 50 MHz 2 x 20 MHz -- 2 x 100 MHz
Serial bus decoding Yes Yes Yes Yes Yes
Display 13.3 in touch
(1920 x 1080)
10.4 in
(1024 x 768)
12.1 in touch
(800 x 600)
12.1 in touch
(1280 x 800)
13.3 in touch
(1920 x 1080)

Embedded serial bus analysis

Serial bus decode and trigger options transform the 4 Series MSO into an indispensable tool for debugging serial buses with automatic decode, trigger, and search. Here are a few examples:

  • I2C, SPI
  • I3C
  • RS-232 / 422 / 485 / UART
  • USB 2.0
  • Ethernet

See the datasheet for all supported buses.

Learn about SPI bus decoding and triggering

Learn about I2C bus decoding and triggering

SPI BUS
MSO 4 Series Power Rail

Power integrity and power management

Today’s boards can have 20 or more power rails, many of which are less than a few volts with strict noise limits.

  • Up to 6 analog input channels
  • Compatible low-noise power-rail probes
  • Decoding options for SVID and SPMI

Learn about measuring ripple and noise on power rails

Power supply measurements and analysis

Even with lower standby power, faster switching and stricter noise limits, the 4 Series can speed up power supply troubleshooting, optimization and validation.

  • AC line and harmonics measurements
  • Switching loss analysis
  • DC power rails measurements
  • Bode plots and power supply rejection ratio
  • Wide range of current, power rail, differential, and optically-isolated probes

Learn about power supply analysis

MSO 4 Series Power Application
4 Series B MSO 3 Phase

3-phase power analysis

Make stable 3-phase power measurements even on pulse-width modulated waveforms. The 3-phase analysis package makes it easy.

Highlights

  • Up to 6 analog input channels
  • 3-phase wye, delta, and single-phase wiring configurations
  • Comprehensive power measurements
  • Harmonics analysis

Learn how to make measurements on 3-phase motor drives and inverters

Discover the EV Traction Inverter Analysis Reference Solution

Automotive ECU design

Automotive systems demand robust communications between ECUs, sensors and actuators.

  • Mixed signal views to look beyond processors at sensors, actuators, switches, and power
  • Combine waveform and spectrum analysis for fast noise hunting with optional Spectrum View
  • Decode and trigger on CAN, CAN FD, LIN, FlexRay, SENT or PSI5 traffic

Learn about CAN bus decoding and triggering

Learn about SENT bus decoding and triggering

Automotive ECU design
4 Series B MSO Remote Control eScope

Remote control and automation

Get fast, repeatable results and access your data from anywhere. Discover test automation resources including our free Python Drivers Package

  • TekScope PC Software offers the same analysis capability available on Tektronix oscilloscopes, on your PC
  • KickStart Software simplifies data capture and logging. Supports function generators, power supplies, SMUs and more
  • Built-in *eScope or Windows Remote Desktop let you control your scope over any LAN
  • Comprehensive, fully-supported programmable interfaces enable development of robust custom software

Learn about tools for remote work and collaboration

Electromagnetic interference (EMI) troubleshooting

With the Spectrum View option each analog channel on the 4 Series MSO can show you a time domain waveform, a spectrum, or both. The time and frequency plots are synchronized to help you quickly determine which signals are the victims and which ones are the aggressors.

Learn about mixed domain analysis

Electromagnetic interference (EMI) troubleshooting

Starter

HKD 13,700

Subscription

HKD 34,200

Perpetual

Select license option to continue

  • Serial trigger, decode, search and event table analysis on I2C, SPI, RS-232/422/485/UART buses
  • Integrated Arbitrary/Function Generator with 13 predefined waveform types as well as arbitrary waveforms

Learn about maintenance for software and licenses

View Brochure

Average Savings of 61%!

Pro

  • Includes Starter Bundle
  • Adds 62.5 M/ch record length

Purchase a Pro or Ultimate software bundle and get 12 months of maintenance included.

View Brochure

Average Savings of 76%!

PLUS: Choose a bundle

Aerospace

HKD 27,400

Subscription

HKD 66,100

Perpetual

  • Mask/limit testing
  • ARINC 429 decoding
  • MIL-STD-1553 decoding
  • NRZ decoding
  • SpaceWire decoding

Select license option to continue

Automotive

HKD 27,400

Subscription

HKD 66,100

Perpetual

  • CAN, CAN FD decoding
  • CXPI decoding
  • Double pulse testing
  • FlexRay decoding
  • I3C decoding
  • LIN decoding
  • PSI5 decoding
  • SENT decoding

Select license option to continue

Power

HKD 27,400

Subscription

HKD 68,400

Perpetual

  • 3-phase power analysis
  • Advanced power analysis
  • Double pulse testing
  • SPMI decoding
  • SVID decoding

Select license option to continue

Serial Decode

HKD 27,400

Subscription

HKD 66,100

Perpetual

  • 1-Wire
  • Audio
  • CAN, CAN FD
  • CXPI
  • EtherCAT
  • Ethernet
  • eSPI
  • eUSB
  • FlexRay
  • I3C
  • LIN
  • Manchester
  • MDIO
  • MIPI D-PHY
  • NFC
  • NRZ
  • SDLC
  • SMBus
  • SPMI
  • SVID
  • USB 2.0

Select license option to continue

Ultimate

HKD 50,200

Subscription

HKD 123,000

Perpetual

Select license option to continue

  • Includes Starter bundle and all Pro bundles
  • PLUS: Spectrum View RF vs. time waveforms, extended Spectrum View capture bandwidth, and video triggers

Purchase a Pro or Ultimate software bundle and get 12 months of maintenance included.

View Brochure

Average Savings of 90%!

  • Opt. 4-3PHASE

    Three-phase analysis

  • Opt. 4-AFG

    Add built-in Arbitrary/Function Generator

  • Opt. 4-MTM

    Mask Testing

  • Opt. 4-PS2

    Power Solution Bundle (4-PWR-BAS, THDP0200, TCP0030A, 067-1684-XX deskew fixture)

  • Opt. 4-PWR

    Advanced power measurement and analysis

  • Opt. 4-PWR-BAS

    Power measurement and analysis

  • Opt. 4-RFNFC

    NFC wireless protocol decoding and search

  • Opt. 4-RL-1

    Extend record length to 62.5 Mpoints/channel

  • Opt. 4-SEC

    Add password-protected enabling and disabling of all communication ports and firmware upgrades

  • Opt. 4-SRAERO

    MIL-STD-1553 and ARINC 429 protocol trigger and decode of serial packet content

  • Opt. 4-SRAUDIO

    I2S, LJ, RJ, and TDM protocol trigger and decode of serial packet content

  • Opt. 4-SRAUTO

    CAN, CAN FD, LIN, and FlexRay protocol trigger and decode of serial packet content.

  • Opt. 4-SRAUTOSEN

    SENT prototcol trigger and decode of serial packet content

  • Opt. 4-SRCOMP

    RS-232/422/485/UART protocol trigger and decode of serial packet content

  • Opt. 4-SRCXPI

    CXPI protocol decoding and analysis

  • Opt. 4-SREMBD

    I2C and SPI protocol trigger and decode of serial packet content

  • Opt. 4-SRENET

    10BASE-T and 100BASE-TX protocol search and decode of serial packet content

  • Opt. 4-SRESPI

    eSPI protocol decoding and analysis

  • Opt. 4-SRETHERCAT

    EtherCAT protocol decoding and analysis

  • Opt. 4-SREUSB2

    eUSB2 protocol decoding and analysis

  • Opt. 4-SRI3C

    I3C protocol trigger and analysis of serial packet content

  • Opt. 4-SRMANCH

    Manchester decoding and analysis

  • Opt. 4-SRMDIO

    MDIO protocol decoding and analysis

  • Opt. 4-SRNRZ

    NRZ protocol decoding and analysis

  • Opt. 4-SRONEWIRE

    1-Wire protocol decoding and analysis

  • Opt. 4-SRPM

    SPMI prototcol trigger and decode of serial packet content

  • Opt. 4-SRPSI5

    PSI5 serial decode and analysis

  • Opt. 4-SRSDLC

    Synchronous data link control (SDLC) decoding and analysis

  • Opt. 4-SRSMBUS

    SMBus protocol decoding and analysis

  • Opt. 4-SRSPACEWIRE

    SpaceWire protocol decoding and analysis

  • Opt. 4-SRSVID

    SVID protocol decoding and analysis

  • Opt. 4-SRUSB2

    Automated compliance testing and verification of USB 2.0 and 3.0 for low-speed, full-speed, high speed and superspeed

  • Opt. 4-SV-BAS

    Spectrum View frequency-domain analysis

  • Opt. 4-SV-BW-1

    Increase Spectrum View Capture Bandwidth to 500 MHz (4-SV-BAS required)

  • Opt. 4-SV-RFVT

    Spectrum View RF versus time analysis and trigger (4-SV-BAS required)

  • Opt. 4-VID

    Analog video trigger (NTSC, PAL, SECAM)

  • Opt. 4-WBG-DPT

    Wide bandgap (SiC/GaN) double pulse test application

Add Instrument Functions

Upgrade Description Purchasing Details
TLP058 Logic Probe Each probe accesses 8 digital channels on any FlexChannel input Request a quote

Add Instrument Functions

Upgrade Description Purchasing Details
SUP4-AFG Add arbitrary function generator Request trial license

Request a quote
SUP4-DVM Add digital voltmeter / trigger frequency counter Software upgrade license key provided upon registration

Register now
SUP4-RL-1 Extend record length from 31.25Mpts / channel to 62.5 Mpts / channel Request trial license

Request a quote

Add Protocol Analysis

Upgrade Description Purchasing Details
SUP4-RFNFC NFC wireless protocol decoding and search Request trial license

Request a quote
SUP4-SRAERO Aerospace serial triggering and analysis (MIL-STD-1553, ARINC429) Request trial license

Request a quote
SUP4-SRAUDIO Audio serial triggering and analysis (I2S, LJ, RJ, TDM) Request trial license

Request a quote
SUP4-SRAUTO Automotive serial triggering and analysis (CAN, CAN FD, LIN, FlexRay) Request trial license

Request a quote
SUP4-SRAUTOSEN Automotive sensor serial triggering and analysis (SENT) Request trial license

Request a quote
SUP4-SRCOMP Computer serial triggering and analysis (RS-232/422/485/UART) Request trial license

Request a quote
SUP4-SRCXPI CXPI protocol decoding and analysis Request trial license

Request a quote
SUP4-SREMBD Embedded serial triggering and analysis (I2C, SPI) Request trial license

Request a quote
SUP4-SRENET Ethernet serial triggering and analysis (10Base-T, 100Base-TX) Request trial license

Request a quote
SUP4-SRESPI eSPI protocol decoding and analysis Request trial license

Request a quote
SUP4-SRETHERCAT EtherCAT protocol decoding and analysis Request trial license

Request a quote
SUP4-SREUSB2 eUSB2 protocol decoding and analysis Request trial license

Request a quote
SUP4-SRI3C I3C serial triggering and analysis Request trial license

Request a quote
SUP4-SRMANCH Manchester decoding and analysis Request trial license

Request a quote
SUP4-SRMDIO MDIO protocol decoding and analysis Request trial license

Request a quote
SUP4-SRNRZ NRZ protocol decoding and analysis Request trial license

Request a quote
SUP4-SRONEWIRE 1-Wire protocol decoding and analysis Request trial license

Request a quote
SUP4-SRPM Power Managent serial triggering and analysis (SPMI) Request trial license

Request a quote
SUP4-SRPSI5 PSI5 serial decode and analysis Request trial license

Request a quote
SUP4-SRSDLC Synchronous Data Link Control (SDLC) decoding and analysis Request trial license

Request a quote
SUP4-SRSMBUS SMBus protocol decoding and analysis Request trial license

Request a quote
SUP4-SRSPACEWIRE SpaceWire protocol decoding and analysis Request trial license

Request a quote
SUP4-SRSVID SVID protocol decoding and analysis Request trial license

Request a quote
SUP4-SRUSB2 USB 2.0 serial bus triggering and analysis (LS, FS, HS) (≥ 1 GHz model recommended for HS) Request trial license

Request a quote

Add Advanced Analysis

Upgrade Description Purchasing Details
SUP4-MTM Mask and limit testing Request trial license

Request a quote
SUP4-3PHASE Three-phase analysis Request trial license

Request a quote
SUP4-PWR Advanced power measurement and analysis Request trial license

Request a quote
SUP4-PWR-BAS Power analysis Request trial license

Request a quote
SUP4-SV-BW-1 Increase Spectrum View Capture Bandwidth to 500 MHz (4-SV-BAS or SUP4-SV-BAS required) Request trial license

Request a quote
SUP4-SV-RFVT Spectrum View RF versus time analysis and trigger (4-SV-BAS required) Request trial license

Request a quote
SUP4-VID Analog video trigger (NTSC, PAL, SECAM) Request trial license

Request a quote
SUP4-WBG-DPT Wide bandgap (SiC/GaN) double pulse test application Request trial license

Request a quote

Upgrade Bandwidth

Upgrade Description Purchasing Details
SUP4-BW4 Bandwidth upgrade for 4 Series MSO with 4 FlexChannel inputs. See datasheet for options.
SUP4-BW6 Bandwidth upgrade for 4 Series MSO with 6 FlexChannel inputs. See datasheet for options.
Current Probes
Datasheet Link Probe Description Configure and Quote
TCP0020 Probe, AC/DC Current; 20 Amp; 50 MHz BW; TekVPI Interface; Certificate of Traceable Calibration Standard Configure & Quote
View Datasheet TCP0030A Probe, AC/DC Current; 30 Amp DC, DC TO 120 MHZ; with TekVPI Interface; Certificate of Traceable Calibration Standard Configure & Quote
View Datasheet TCP0150 Current Probe: 20 MHz, 5 mA to 212 A, AC/DC, TekVPI Configure & Quote
View Datasheet TRCP0300 Current Probe: 30 MHz, 250 mA to 300 A, AC-Only, BNC Interface Configure & Quote
View Datasheet TRCP0600 Current Probe: 30 MHz, 500 mA to 600 A, AC-Only, BNC Interface Configure & Quote
View Datasheet TRCP3000 Current Probe: 16 MHz, 500 mA to 3000 A, AC-Only, BNC Interface Configure & Quote
High Voltage Differential Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TDP0500 Differential Probe: 500 MHz, 5X/50X, +/- 42V, TekVPI Configure & Quote
View Datasheet TDP1000 Differential Probe: 1 GHz, 5X/50X, +/- 42V, TekVPI Configure & Quote
View Datasheet THDP0100 Differential PROBE; 100 MHZ TekVPI DIFFERENTIAL HIGH VOLTAGE PROBE Configure & Quote
View Datasheet THDP0200 Differential PROBE; 200 MHZ TekVPI DIFFERENTIAL HIGH VOLTAGE PROBE Configure & Quote
View Datasheet TMDP0200 Differential PROBE; 200 MHZ TekVPI DIFFERENTIAL MEDIUM VOLTAGE PROBE;TMPD0200 Configure & Quote
High Voltage Probe: Single-Ended
Datasheet Link Probe Description Configure and Quote
P6015A PROBE HIVOLTAGE; 75MHZ,40KV,1000X 10 FT - CERTIFICATE OF TRACEABLE CALIBRATION STANDARD Configure & Quote
View Datasheet TPP0850 High Voltage Probe: 800 MHz, 50X, 2.5 kV, Single-ended, TekVPI Configure & Quote
IsoVu Isolated Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TIVP02 IsoVu Gen. 2 optically isolated differential probe, 200 MHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP02L IsoVu Gen. 2 optically isolated differential probe, 200 MHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP05 IsoVu Gen. 2 optically isolated differential probe, 500 MHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP05L IsoVu Gen. 2 optically isolated differential probe, 500 MHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP1 IsoVu Gen. 2 optically isolated differential probe, 1 GHz, TekVPI, 2 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
View Datasheet TIVP1L IsoVu Gen. 2 optically isolated differential probe, 1 GHz, TekVPI, 10 m cable, includes 10X (TIVPMX10X) tip Configure & Quote
Logic Probe
Datasheet Link Probe Description Configure and Quote
TLP058 8 channel general purpose logic probe for 5 and 6 Series MSO oscilloscopes. Includes accessory kit. Configure & Quote
Low Voltage Differential Oscilloscope Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TDP1500 Differential Probe: 1.5 GHz, 1X/10X, +/-8.5V, TekVPI Configure & Quote
View Datasheet TDP3500 Differential Probe: 3.5 GHz, 5X, +/- 2V, TekVPI Configure & Quote
View Datasheet TDP4000 4 GHz, Differential Probe with TekVPI interface Configure & Quote
Low Voltage Probes: Single-Ended
Datasheet Link Probe Description Configure and Quote
View Datasheet TAP1500 Active Probe: 1.5 GHz, 10X, Single-ended, TekVPI Configure & Quote
View Datasheet TAP2500 Active Probe: 2.5 GHz, 10X, Single-ended, TekVPI Configure & Quote
View Datasheet TAP3500 Active Probe: 3.5 GHz, 10X, Single-ended, TekVPI Configure & Quote
View Datasheet TAP4000 4 GHz, Single Ended Probe with TekVPI interface Configure & Quote
Passive Probe
Datasheet Link Probe Description Configure and Quote
View Datasheet TPP0250 Passive Probe: 250 MHz, 10X, TekVPI Configure & Quote
View Datasheet TPP0500B Passive Probe: 500 MHz, 10X, TekVPI Configure & Quote
View Datasheet TPP0502 Passive Probe: 500 MHz, 2X, TekVPI Configure & Quote
View Datasheet TPP1000 Passive Probe: 1 GHz, 10X, TekVPI Configure & Quote
Power Rail Probes
Datasheet Link Probe Description Configure and Quote
View Datasheet TPR1000 1 GHz, Single-Ended TekVPI Power-Rail Probe with TPR4KIT Standard Accessory Kit Configure & Quote
View Datasheet TPR4000 4 GHz, Single-Ended TekVPI Power-Rail Probe with TPR4KIT Standard Accessory Kit Configure & Quote
Accessory HC4
Datasheet Description
View Datasheet Hard transit case for the 4 Series MSO (includes front cover)
Accessory RM4
Datasheet Description
View Datasheet Rack mount kit for the 4 Series MSO
Accessory SC4
Datasheet Description
View Datasheet Soft carrying case and front protective cover for the 4 Series MSO
Accessory TEK-DPG
Datasheet Description
Accessory, Deskew Pulse Generator Signal Source with TekVPI Scope Interface
Accessory TPA-BNC
Datasheet Description
Probe adapter from TekProbe-BNC to TekVPI
Datasheet Accessory Description
HC4 Hard transit case for the 4 Series MSO (includes front cover)
RM4 Rack mount kit for the 4 Series MSO
SC4 Soft carrying case and front protective cover for the 4 Series MSO
View Datasheet TEK-DPG Accessory, Deskew Pulse Generator Signal Source with TekVPI Scope Interface
View Datasheet TPA-BNC Probe adapter from TekProbe-BNC to TekVPI

Tektronix offers a range of calibration and warranty extension plans for purchase with your instrument to protect and maintain its performance over the years. Benefits include:

  • OEM quality maintenance
  • Priority on-bench service
  • A host of accident protection, loaner program, and other program features
  • A breadth of calibration service levels and options

Invest now to avoid unplanned downtime and expense. Talk to your sales rep about adding a service plan to your instrument purchase.

Tektronix Calibration Services

Protect Your Investment, Protect Your Uptime

Configure & Quote


Service Plan Feature
Total Protection
(Opt. T3, T5)
Tek Care
(Opt. R3, R5)
Extension of factory warranty
Protection from manufacturer defects
Free factory certified calibration with repair (if necessary)
Free in-country shipping
Priority on-bench service
Coverage of user-caused EOS and ESD damage
Coverage from accidental damage
Coverage from normal wear and tear

Maintain Accuracy, Get Updates, Pass Audits

Configure & Quote


Calibration Features:
Z540
Calibration1
ISO 17025
Compliant1
ISO 17025
Accredited
Certificate of calibration and calibration label designed to meet audit requirements
Firmware updates, if applicable, along with safety and reliability updates ²
OEM procedures for measurements ²
Test data Optional
Calibration record retention
Traceability
Uncertainty analysis
Independent verification by a ISO/IEC accredited organization (with logo on certificate)

Product/Option
Description
Tektronix Opt. C3 Calibration service 3 years. C3 provides for 2 calibration events during 3 years after shipment.  Includes traceable calibration or functional verification where applicable, for recommended calibrations.  Coverage includes the initial calibration plus 2-years calibration coverage.
Tektronix Opt. C5 Calibration service 5 years. C5 provides for 4 calibration events during 5 years after shipment.  Includes traceable calibration or functional verification where applicable, for recommended calibrations.  Coverage includes the initial calibration plus 4-years calibration coverage.

1 May be ISO 9001 in specific locations.

2 Standard with factory certified service.

Some limits apply, see program terms for details.

Need to Calibrate More than Just Your 4 Series?

Tektronix is a leading accredited calibration services provider for all brands of electronic test and measurement equipment, servicing more than 140,000 models from 9,000 manufacturers. With 100+ labs worldwide, Tektronix serves as your single global partner delivering tailored calibration programs with OEM quality at a market price. Onsite, local pickup and delivery, and other options available.

Tektronix Calibration Services
